FRP submerged pump

FSY type, WSY type, pump No., parts:

No.
  Name
1
  Imported shower head
2
  Impeller cap
3
  Impeller gasket
4
  Lower sleeve
5
  Lower bushing
6
  Washer
7
  Lower casing
8
  Pump housing gasket
9
  Impeller
10
  Upper pump body
11
  Upper bushing
12
  Upper sleeve
13
  Pump shaft
14
  Sealing seat
15
  Gland packing
16
  Gland
17
  Base
18
  Elbow gasket
19
  FRP bend
20
  Bearing lower closure
21
  Oil seal
22
  Bearing
23
  Intermediate seat
24
  Electric motor base
25
  Bearing seat
26
  Bearing
27
  Upper bearing gland
28
  Spacer sleeve
29
  Pump mp coupling
30
  Elastic block
31
  Motor coupling
32
  Motor
33
  Hexagon bolt
34
  Hexagonal nut
35
  Washer
36
  Hexagon bolt
37
  Hexagon bolt
38
  Washer
39
  Hexagon bolt
40
  Anti-corrosion nut
41
  Anti-corrosion gasket
42
  Double-headed stud


Specifications and performance parameters:

No. ModelsSpecifications Flow（Q） Head
（H）米		 Revolutions
（N）转/分		 PowerN（千瓦） Efficiency% Impeller diameter
（D）毫米		 Submerging depth（mm）
m3/h L / sec Axle Motor
1 40FSY-18 6.48
15.00
21.60		 1.80
4.17
6.00		 18
15
12		 2900 1.00
1.20
1.76		 2.2 32
51
40		 132 800至3000
2 40FSY-22 8.10
15.84
21.60		 2.24
4.40
5.50		 22
18
15		 2900 1.09
1.45
1.83		 3 44
53
44		 140
3 40FSY-25 10.00
20.00
30.00		 2.80
5.50
8.30		 25
20
17		 2900 1.56
2.42
2.88		 4 43
45
47		 160
4 40FSY-35 10
20
30		 2.8
5.5
8.3		 34
30
24		 2900 1.86
2.62
3.09		 4 50.6
64
63.5		 162
5 50FSY-20 18
30
35		 5.0
8.3
9.7		 20
16
12		 2900 1.64
2.4
2.6		 4 60
55
44		 150
6 50FSY-35 30
45
55		 8.3
12.5
15.1		 35
32
28		 2900 4.94
5.59
6.33		 7.5 58
70
66		 182
7 50FSY-35A 25
35
45		 7.0
9.7
12.5		 26
25
22		 2900 2.83
3.35
3.87		 5.5 63
70
69		 168
8 80FSY-35 56
92
110		 15.5
25.5
30.5		 35
29
25		 2900 8.45
10.1
10.8		 15 63
72
69		 184
9 80FSY-35A 45
69
90		 12.5
19.5
25.0		 26
22
19		 2900 5.12
6.2
7.35		 11 62
67
63		 163
