All plastic water jet vacuum unit
Application range and structure:
Changjia all plastic water jet vacuum unit is new-model anti-corrosive vacuum acquisition equipment that is widely used in chemical, pharmaceutical, textile, environment protection, drying and other fields for advantages such as reasonable structure, strong corrosion resistance, energy conservation and environment protection, long service life, and etc.
.jpg)
Specifications and technical parameters:
| Specifications | Guaranteed vacuum | Maximum pumping capacity m3/h | Model and power of matching pumpKw | Dimensions of horizontal unitmm | |
| MPa | mmHg | ||||
| RPP-20 | 0.098 | 735 | 20 | 40FP-18(1.5) | 1000×600×900 |
| RPP-40 | 0.098 | 735 | 40 | 50FP-22(2.2) | 1000×700×900 |
| RPP-60 | 0.097 | 728 | 60 | 50FP-25(3.0) | 1300×800×1050 |
| RPP-90 | 0.097 | 728 | 90 | 65FP-28(4.0) | 1400×800×1050 |
| RPP-110 | 0.097 | 728 | 110 | 80FP-30(5.5) | 1800×900×1200 |
| RPP-180 | 0.098 | 735 | 180 | 80FP-30(5.5) | 1900×900×1200 |
| RPP-220 | 0.098 | 735 | 220 | 100FP-32(15) | 2100×1000×1350 |
| RPP-280 | 0.098 | 735 | 280 | 80FP-32(7.5) | 2100×1000×1350 |
| RPP-360 | 0.098 | 735 | 360 | 100FP-32(11) | 2200×1200×1350 |
| RPP-500 | 0.098 | 735 | 500 | 100FP-32(15) | 2300×1200×1400 |
